Specifications
Dimensions and Weights
-
Body type
-
Door configuration
-
Passenger capacity
-
Kerb weight
-
Length
-
Width
-
Height
-
Floor to ceiling height
-
Step-in height
Electric drive
-
Maximum range
-
Rated voltage
-
Maximum power
-
Maximum traction torque
Batteries
-
Cell chemistry
-
Cell capacity and voltage
-
Pack capacity
-
Pack capacity - long range
Axles
-
Front (1st) Axle Capacity
-
2nd Axle Capacity
-
3th Axle Capacity
Rims and Tires
-
Rim
-
Tire
Ebusco
2.2 - 12M
12M
2.2 - 12M
Dimensions and Weights
-
Body type
-
Low entry / Low floor+
-
Door configuration
-
2 / 3 doors+
-
Passenger capacity
-
89 persons+
-
Kerb weight
-
13580 kg+
-
Length
-
12000 mm+
-
Width
-
2550 mm+
-
Height
-
3250 mm+
-
Floor to ceiling height
-
2400 mm+
-
Step-in height
-
340 mm+
2.2 - 12M
-
Maximum range
-
550 km+
-
Rated voltage
-
AC 3ф 400V+
-
Maximum power
-
2 x 125 kW+
-
Maximum traction torque
-
22000 Nm+
2.2 - 12M
-
Cell chemistry
-
LFP (inherent fireproof battery)+
-
Cell capacity and voltage
-
228 Ah, 3.22 V* or 302Ah, 3.22V*+
-
Pack capacity
-
>400 kWh+
-
Pack capacity - long range version
-
>500 kWh+
2.2 - 12M
-
Front Axle Capacity
-
8165 kg+
-
Rear Axle Capacity
-
11500 kg+
-
3th Axle Capacity
-
+
2.2 - 12M
-
Rim
-
22.5 x 7.5+
-
Tire
-
275 / 70R / 22.5 Continental HA3 M + S or 275/70R22.5 Michelin X InCity EV Z+
